Eclipse
Part of the Origami Collection, a collaboration with paper artist Paul Jackson.
Resources
Download the product cut sheet for all documentation, sustainability and rating information.
Eclipse Tile
Eclipse was developed using his many years of experience as a professional paper artist to re-form a sheet of felt from flat to a three-dimensional form simply by cutting and folding the material. The folding of the tile creates the sense of the geometric shape passing into the shadow of another. Simply by changing their orientation in the grid, you can create an unlimited variety of patterns.
Installation types:
Drop the tiles into any 9/16” or 15/16” tee-grid.
Concealed tile install - tiles fit neatly together edge-to-edge, to conceal the actual grid.
Slight variations in color should be expected when using this material. We recommend requesting a sample to verify colors.
-
![]()
F:02 Light Gray
-
![]()
F:03 Medium Gray
How to spec
-
9/16”
15/16”
-
Lay-in (exposed grid)
Concealed below grid (hides grid) 15/16” grid only
-
Open will be exposed to the ceiling above.
Closed will be an additional layer to enclose the ceiling.
-
F:02 Light Gray
F:03 Medium Gray
F:04 Dark Gray
F:05 Warm Gray
-
F:02 Light Gray
F:03 Medium Gray
F:04 Dark Gray
F:05 Warm Gray
-
You can select an accent color to be applied to the product. Fabrics can be applied to one surface only. If multiple surfaces are required, please reach out to your local rep to discuss the project.
Category A:
-
Product Specs
Material
9mm Polyester (PET) Felt
Flammability
ASTM E84 Class A Certified
CAN/ULC-S102.2
Size
23.75” x 23.75” x 9”D
Sustainability
Polyester (PET) Felt
60% Pre-Consumer Recycled
Weight
3.12 lb
Installation
Installs on 9/16” or 15/16” Tee-Grid System
Warranty
3 Year Limited Liability
Shipping
4 Week Lead Time
Construction
6" clearance required above grid. In areas where you do not have this clearance, the flat tile is required.
Installations
Request a Quote
Reach out with your project needs and goals. We can provide you with the right acoustic solution for your space, quickly and with straightforward pricing.
